16
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 48cm(19")
Pixel pitch 0.294mm( H )x 0.294mm( V )
Brightness
300cd/m 2 (Typical)
Contrast 700:1(Typical)
Viewable angle 150° (H) 135° (V)
Response time 8ms
R,G,B Analog Interface
Video
Digital interface(Only Dual-Input
Model)
H-Frequency 30KHz – 80KHz
V-Frequency 55-75Hz
Display Colors 16.2M Colors
Dot Clock 135MHz
Max. Resolution 1280 x 1024 @75Hz
Plug & Play VESA DDC2B TM
ON Mode ≤50W EPA ENERGY STAR ®
OFF Mode ≤ 2W
D-Sub 15pin Input Connector
DVI-D 24pin (Only Dual-Input Model)
Analog:0.7Vp-p(standard),
75 OHM, Positive
Input Video Signal
Digital signal (Only Dual-Input
Model)
Maximum Screen Size Horizontal : 376.32mm
Vertical : 301.056mm
Power Source 100~264VAC,47~63Hz
Environmental
Considerations Operating Temp: 0° to 40°C
Storage Temp.: -20° to 65°C
Operating Humidity: 10% to 85%
Dimensions 417X427X164(W×H×D)mm
Weight (N. W.) 5.4kg Unit (net)
Input
