MULTI-TASKER
7
Example:
If one MT108-105 card is plugged in slot #2 of
unit 3:
Send the command [VERC2U3], and the
Multi-Tasker™ Basic Enclosure will return the
following feedback:
MT108-105 690-0127-007
690-0127-007 = software version
MT108-105 = card type: MT108-105
2. [C]
This command receives the status of the card.
Command Format: [CnUi]
Cn = card ID (n = from 1 to 19)
(1-8 for MT100-101 or 1-4 for MT100-106)
Ui = unit ID (i = from 0 to 9) (refer to the
MT100-100 user’s guide for explanation)
Example:
If one MT108-105 card is plugged in slot #2 of
unit 3, sending the
[C2U3] command , the
Multi-Tasker™ Basic Enclosure will return
feedback as:
Vol1=16/16
Vol2=12/16
Vol3=8/16
Vol4=4/16
There are 16 levels for amplitude. In the above
example, Input 1 (Vol1) is at level 16 out of 16
or maximum amplitude. Input 2 is at 12 or ¾
amplitude. Input 3 is at ½ volume and Input 4 is
at ¼ volume.
If there is no card plugged into slot #2 of unit 3,
the Multi-Tasker™ Basic Enclosure will not
return any feedback.
3. [CiS]
This command saves the current status of the
card's output volume configuration. This
configuration will be restored after system is
reset or powered off then on.
Ci = card number
S = save configuration
If Outputs 1 and 2 are at volume level 16 and
outputs 3 and 4 are at level 8, the feedback
after sending the command [C4S], for slot 4,
would be:
Vol1=16/16
Vol2=16/16
Vol3=8/16
Vol4=8/16
Card Status Saved
4. [ + ] or [ - ]
This command increases or decreases volume.
It immediately follows the [SEL] command. Any
command other than [ + ] or [ - ] will reset the
previous selection and the [SEL] command will
need to be reissued.
Example:
If the status of audio card 2 of unit zero is as
follows:
Vol1=16/16
Vol2=0/16
Vol3=0/16
Vol4=0/16
Send the commands:
[SEL1C2] [ - ] [ - ]
[SEL2C2] [ + ] [ + ]
[C2]
The new status will be as follows:
Vol1=14/16
Vol2=2/16
Vol3=0/16
Vol4=0/16
Note: The [SEL], [ + ], and [ - ] commands can
also be used to control the volume for a group
of cards.
Command Format: [SELmGkUi]
SELm = select output (m = from 1 to 4)
Gk = group number (k = # from 1-9)
Ui = unit id (i = # from 0-9)
