KM9106 Operators Manual
2
1.2 Analyser Layout
Connection lead
for Oxygen
sensor
Oxygen Sensor
Filter Bridge
or Sulphur Filter
Particle Filter
Battery
enclosure
Printer unit
Handset
(stored in
pocket)
Accessory
storage
space
(leads/water
trap etc.)
Dual
pressure ports
Water trap
connection
Water trap
located on
side of instrument
Instrument case
