Sterlco SDD Series User Manual
Page 17
882.01749.00
17
of
93
“DT” Pellet & Regrind Discs
“DP” Powder Discs
Additive Sample weighing.
Weighing samples of additive provides for more precise control of feed rate. Up to 5
samples can be weighed. All weights entered are averaged to arrive at a value to be used
during operation. The weighing process may be skipped altogether, in which case the
calibration weight is used for calculations of feed rate. See the section Weight Calibration at
the end of this section.
Feeder Configuration – Simple extrusion:
Touch the ACS logo on the main menu screen to access the configuration menu. See section # for
details.
Feeder
Type
Selection. Select simple extrusion.
Disc
Thickness
Disc
Calibration
Number
No. of
Pockets
10 mm
DT 30-101820 32.00 20
DT 30-102025
(“Sure-shot” - 20
oval holes)
38.00
20 Oval
20mm
DT 30-203012 100.00 12
DT 30-204010 175.00 10
Disc
Calibration
Number
Disc
Thickness
DP 30-
050940
17.00
5mm
DP 30-
250940
8.00 2.5mm
