Power Supply features
STANDARD PSU
• Adjustable photocell
• Adjustable power
• Telemetry input
PReMIUM PSU-PR
• Adjustable photocell
• Adjustable power
• Telemetry input
• Photocell following contact, volt
free relay contact - normally open
(day) to normally closed (night)
• 12V DC output @ 1.5A
PULSeD PSU - PU
• Analogue version
• TTL version
• No photocell
• Adjustable power
• 12V DC output @ 1.5A
• Synchronised with camera
PReMIUM TIMeR PSU-PRT
• Adjustable photocell
• Adjustable power
• Telemetry input
• Photocell following contact, volt
free relay contact - normally open
(day) to normally closed (night)
• 12V DC output @ 1.5A
• Timer function
300 200 150 100 50 25
Input x 24V AC/DC x 24V AC/DC 12/24V AC/DC 12/24V AC/DC
Fuse x 5A x 5A 3A 3A
Typical Output
(Infra-Red)
x 4.4A @ 13.5V x 2.4A @ 13.5V 1A @ 13.5V 0.5A @ 13.5V
Typical Output
(White-Light)
x 4.2A @ 13.5V x 2.8A @ 13.5V 1.4A @ 13.5V 0.7A @ 13.5V
Adjustable
Power
x 10% - 100% x 10% - 100% 10% - 100% 10% - 100%
Weight x
1.85 kg
(4.1lbs)
x
1.65 kg
(3.6lbs)
0.9 kg
(2lbs)
0.8 kg
(1.8lbs)
Dimensions
L x W x D
x
160 x 160 x 81mm
(6.3 x 6.3 x 3.2”)
x
160 x 160 x 81mm
(6.3 x 6.3 x 3.2”)
130 x 130 x 60mm
(5.1 x 5.1 x 2.4”)
130 x 130 x 60mm
(5.1 x 5.1 x 2.4”)
Drilling
Dimensions
x
4 x M4 holes
@ 145 x 123mm
(5.7” x 4.8”)
x
4 x M4 holes
@ 145 x 123mm
(5.7” x 4.8”)
4 x M4 holes
@ 113 x 113mm
(4.4” x 4.4”)
4 x M4 holes
@ 113 x 113mm
(4.4” x 4.4”)
Low Voltage PSU (LVP) Specification
INfRA-ReD AND WHITe-LIGHT Series PSU
(excluding Platinum and Covert Series)
NOTe: ensure operating voltage is correct for unit being installed.
DO NOT INPUT MAINS VOLTAGe INTO LOW VOLTAGe PSUs.
!
