17
Note 1: One bank cable connects to no more than one battery
Note 2: ProSport is designed to be used with group 24, 27, 30 and 31 batteries
Fig. 6 ProSport 20, 12 and 8 Two Bank Charger for 2 12V Batteries in Parallel
Important: The pair of red and black wires in 1 cable jacket MUST GO TO THE SAME 12VDC battery.
Dedicated 12 VDC Parallel Trolling Motor or House Configuration
Top View of Battery
+
_
+
_
red
black
red
black
Indicates Jumper Series
Note:
Indicates Fuse
Bat 2 Bat 1 Cable 2 Cable 1
Red Jumper
Black Jumper
For Engine Battery use this Bank Cable Only
Typical Wiring
When connecting each jacketed battery charger cable, make sure it is connected
to only one 12 VDC battery and observe the polarity and color of all connections:
Red Wire = + (Positive) Battery connection
Black Wire = - (Negative) Battery connection
The black wire can never be connected to a terminal with red wires. Only black.
Installation
W I R I N G D I A G R A M S
ProSport 12
16
Note 1: One bank cable connects to no more than one battery
Note 2: ProSport is designed to be used with group 24, 27, 30 and 31 batteries
Fig. 5 ProSport 20, 12 and 8 Two Bank Charger for 2 12V Batteries
Important: The pair of red and black wires in 1 cable jacket MUST GO TO THE SAME 12VDC battery.
Dedicated 24 VDC Trolling Motor Battery Configuration
with (2) 12 VDC Batteries Connected with a Series Jumper
Two 12 VDC Batteries connected with a series
jumper for a 24 VDC Trolling Motor
Top View
of Battery
red black
+
_
red black
+
_
Bat 1 Bat 2
Cable 1 Cable 2
For Engine Battery use
this Bank Cable Only
Typical Wiring
When connecting each jacketed battery charger cable, make sure it is connected
to only one 12 VDC battery and observe the polarity and color of all connections:
Red Wire = + (Positive) Battery connection
Black Wire = - (Negative) Battery connection
The black wire can never be connected to a terminal with red wires. Only black.
Installation
W I R I N G D I A G R A M S
ProSport 12
