EXTRACTOR GROUP
980238 03/08/06
5-2
REF PART
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 75211 1
TANK,
RECOVERY
2
34293
1
FOAM, 4.00 OD X 1.0 THICK
3
70859
2
SCREW, 8-32 X 1/2 FHMS BLK PLTD
4
35168
1
GASKET, 4.06 X 2.50 X .38
5
67511
1
RETAINER, VAC MOTOR
6
270102
1
COVER, VAC MOTOR
7A
53137
1
VAC MOTOR, 120V 2ST LNP
7B
53813
1
VAC MOTOR, 230V 2ST LNP
230V MACHINES ONLY
8
70162
6
SCR, 10-32 X 3/8 PPHMS SS
9
87493
4
WASHER, M6 X 12.5 FLAT SS
10
35160
1
GASKET, SPOTTER RECOVERY
11
35161
1
GASKET, 4.0 X 5.5” X .25 PORON
12A
140839
1
BREAKER, 8A VDE CIRCUIT
12B
140815
1
BREAKER, 4A VDE CIRCUIT
230V MACHINES ONLY
13 OPEN
14 OPEN
15
67481
3
RIVET, M4 X 14 MM
16A
23722
1
CORD ASM, 14 X 3 25’ YLW SPOTTER
U.S. MACHINE
16B
23720
1
CORD ASM, UK SPOTTER
UK MACHINE
16C
23723
1
CORD ASM, EURO SPOTTER
EUROPE MACHINE
16D
23724
1
CORD ASM, AUST SPOTTER
AUSTRILIA
MACHINE
17 OPEN
18 62129 1
PLATE,
DATA
LABEL
19
70556
2
SCREW, 1/4-20 X 1.5 PHMS PLTD
20
87493
2
WASHER, M8 X 22 FLAT PLTD
21
14942
1
BOOT, 3/8 CIRCUIT BREAKER
22 27376 1
CLIP,
SWITCH
RETAINING
23
72194
1
SWITCH, DPST 250V 16(4) SPLASH
24 41278 1
HOUSING,
VAC
25 35173 1
GASKET,
NIPPLE
SEAL
26 35172 2
GASKET,
VAC
HOUSING
3/16”
27
87016
3
WASHER, #10 EXT. TOOTH LOCK
28 OPEN
29 140037 1
BRACKET,
NIPPLE
30A 75210 1
TANK,
SOLUTION
30B 75459 1
TANK,
SOLUTION
SPOTTER
GRAY
31 51320 2
LATCH,
PRESTO
TANK
32
70052
4
SCREW, 8-32 X 3/8 PPHMS SS
33 35368 1
GASKET,
GROUND
WIRE
34
56049
1
NIPPLE, 1/4 X 6.0 BRASS
35
04066
1
ADPTR, 1/8 MPT X 1/4 FPT BRASS
36
270-11A
1
NIPPLE, 1/8 FPT QD MALE BRASS
37
40029
1
HOSEBARB, 1/4 MPT X 3/8
38
31017
1
FITTING, ELBOW, 1/4 FPT X 1/4 FPT
39
70689
1
SCR, M4.8 X 10 HHTF TYPE B
40 140070 1
BULKHEAD,
UNION
41
87136
2
WASHER, .52 ID X .875 OD
42
59034
1
O-RING, 0.36” X 0.56”
43
73250
1
STRAINER, 80 MESH X 3/8 FPT
44
39708
1
HOSE, 3/8 ID SGLBRD RBR X 4.5”
45 20042 2
CLAMP,
HOSE
46 500895 1
LABEL,
WARNING
47 48074 2
KEEPER,
PRESTO
LATCH
48
34290
1
FILTER, EMI 250V 6A 1.75MM
230V MACHINES ONLY
49
27952
1
CAPACITOR ASM, EMI SPOTTER
230V MACHINES ONLY
50 35354 1
GASKET,
VAC
HOUSING
3/8”
