Air blower body assembly – Prochem Apache Air Mover User Manual
Page 13
13
86362950 Apache AM
Air Blower Body Assembly
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86136750
8
SCREW M4 X 15MM PHSM
2
86214700
1
9" BLOWER GRILL
3
86136770
2
SCREW M6 - 1 X 16MM FHMS BLK
4
86271550
6
NUT M6X1 HEX NYLOCK PLTD
5
86279070
8
WASHER, M6 FLAT
6
86136560
1
RIVET, M5 X 20
7
86198450
1
CLAMP, 5/16 DIA NYLON
8
86288680
1
WASHER, M5 RIVET BACKUP
9
86225750
4
WASHER M4 INT STAR BLKZNC PLT
10
86007140
1
SWITCH SPST 2-POSITION ROCKER - WIN.
11
86358180
1
PLATE, SWITCH
12
86137370
1
WASHER, M18 STAR
13
86217020
1
CORD ASSEMBLY, 14X3 SJTX25'AB
14
86079800
1
PLATE, WARNING LABEL
15
86136550
4
RIVET, M3 X 12MM
16
86225850
4
WASHER, M3, FL, ISO 7089, SST
17
86136540
8
RIVET, M4 X 14MM
18
86288700
1
CLAMP, CAPACITION AB
19
86223050
1
PLATE, INNER AB
20
86137360
4
WASHER, M4 RIVET BACKUP
21
86137340
4
WASHER M6 FLAT BLK
22
86136740
2
SCREW M6 - 1 X 15 PHMS BLK
23
86215760
1
BRKT, MOTOR SHAFT AB
24
86214690
1
10" BLOWER GRILL
25
86136830
1
SET SCR, M8 X 8MM CUP PT.
26
86217840
1
FAN, SQUIRREL CAGE AB
27
86136760
4
SCR, M6 X 20, BSHCS, ISO380, SST
28
86217910
4
FOOT, BLOWER
29
86137390
2
WASHER M4 RIVET BACKUP
30
86136730
2
SCREW M6 - 1 X 40MM PLTD
31
86218420
1
GUARD, FRONT AB
32
86216760
1
CLAMP, CARPET AB
33
86219710
2
KNOB, CARPET CLAMP
34
86358210
1
MOTOR, 120VAC, 60HZ, 250W
35
86216620
1
CAPACITOR, AB
36
86245040
1
LABEL, GROUND SYMBOL
37
86245090
1
LABEL, WB3-UL WARNING
38
86372180
4
SCREW, M4-.7 X 10 PNHSMS, BLK
