Prochem Warrior Air Mover - Manual (Page 3)

POWER
CORD
ARK-LES
U R
1
2, 2A, 2B 3
4
5
6
7
9
8, 8A
10
13
12
11
14
1
2
2A
2B
3
4
5
6
7
8
8A
9
10
11
12
13
14
15
16
17
18
19
20
58-500694......HOUSING
40-902124......MOTOR, 1/3 HP
40-902127......MOTOR, 1/2 HP
40-902131......MOTOR, 3/4 HP
44-802249......SWIRL CAGE
32-900189......SWITCH, 3-SPEED
48-941244......DECAL, SWITCH
48-941246......DECAL, WARRIOR
31-900201......STRAIN RELIEF, POWER CORD
64-900095......POWER CORD 110v 18-3 (1/3 HP)
64-900094......POWER CORD 110v 14-3 (1/2 & 3/4 HP)
03-000251......CABLE CLAMP
04-000298......SWITCH KNOB
49-876159......FOOT BUMPER
00-000360......RIVIT
58-700034......VIBRATION PAD, MOTOR
00-000078......SCREW, 1/4-20 x 1" HXHD
01-000023......LOCKNUT, 1/4-20 sst
01-000279......LOCKNUT, SWITCH
02-000066......FLATWASHER, 1/4
02-000280......WASHER, FENDER 1/4 x 1"
02-000279......STARWASHER, INT 5/16
02-000276......BACKING WASHER, RIVIT
15
16
17
18
1 2 3
B
BLACK
BLUE
RED
BLACK
TO
MOTOR
TO
MOTOR
WHITE
GREEN
BLACK
WHITE
GREEN
Back of Switch
POWER
CORD
BUTT
CONNECTORS
WARRIOR
BIS
ON
19
20
WARRIOR
AIR MOVER
1/3, 1/2, & 3/4 HP
