6
1. Unplug and position in an area where water will do no
damage.
2. Place a container behind the unit, loosen the knob at
the rear low plate and the water will flow from the tank
into the container.
3. Unscrew and release the rear plate.
4. Pull out the terminals and take out the air filter
together with the rear plate.
5. Clean the air filter. Be careful not to splash the small motor with water. Do not
wash the small motor with running water.
6. Replace the air filter, screw back the rear plate and replace the knob.
Pull out the
terminals
Air filter
Unscrew
Small motor
Do not dip the
small motor in
water.
Don’t wash the
small motor
with running
water.
Rear plate
HOW TO CLEAN THE AIR FILTER AND WATER TANK
Voltage and frequency 220 - 240 V / 50 Hz
Power cool:
hot:
W
75 - 91
860 - 1040 (L) / 1720 - 2090 (H)
Water consumption
(at room temperature 28°–33°C
and relative humidity 55–60%)
L/h 0.5
Water reservoir capacity 9 litres for upto 18 hours continuous
usage at 28°–33°C
(55–60% relative humidity)
Ice cubes reservoir L 4.2
Dimensions (W x D x H) cm 43.5 x 34 x 64.5
Net weight kg 10.5
TECHNICAL DATA
GB
