Specifications
User Manual STEREO
1
MXL Revelation Stereo
Thank you for choosing the MXL Revelation Stereo microphone.
Your Revelation Stereo microphone was designed and engineered
in the United States by MXL’s world-class team. It features two
6-micron capsules that are stacked in a 90-degree coincident-pair
configuration to capture stereo recordings with the maximum
fidelity, as well as two hand-selected EF86 vacuum tubes and
individual balanced output transformers. As a member of MXL’s
flagship series of studio microphones, the Revelation Stereo
delivers the warmth, accuracy and clarity that are associated
with only the finest recording equipment.
Your Revelation Stereo microphone will provide many years of
outstanding service and recordings of the highest quality. Please
review this manual before you get started. You’ll find recording tips
and other information that will help you obtain the best results.
Enjoy your microphone!
The MXL Team
6
Warranty
MXL microphones are guaranteed against defects in materials and workmanship for three
years (except for the tubes, which is 90 days) from the date of purchase. If you encounter
any problem with this unit, promptly contact the company from which you purchased it for
assistance. The original dated sales receipt will be necessary for any warranty claim. Do not
send any unit directly to us without prior authorization from our service department.
Warranty coverage is limited to repair or replacement (at our option) of the microphone
and does not cover incidental damages due to use of this unit, nor damage caused by
accidental misuse of this product.
Type: Stereo Tube Condenser
Microphone
Tube Type: EF86
Frequency Response: 20Hz—20kHz
Polar Pattern: Fixed 90° X/Y
Sensitivity: -40 dB re 1 V/Pa
Impedance: 140 ohms
Attenuation Switch: 0 dB, -10 dB
High-Pass Filter: 12 dB/octave at 125Hz
Max SPL for 0.5% THD: 138 dB SPL
S/N Ratio: 76 dB
Power Requirements: Revelation Stereo Power Supply
Unit 110/220 VAC, 50/60Hz
Size: 11 1/2" x 2 1/2"
Weight: 3 lbs
Metal Finish: Purple and Chrome
