SPECIAL APPLICATION
400-0442-006 4
MECHANICAL DS801-111
Housing 0.036” Aluminum
Front Panel 0.035” Steel
Length 4.10 in (104 mm)
Width 1.38 in (35 mm)
Height 1.20 in (30 mm)
Weight 0.25 lb (0.11 kg)
T° Operating 10°C-50°C
T° Maximum 75°C
Humidity 90% non-condensing
MTBF (calc.) 38,000 hrs
Table 2. DS801-111 Mechanical
ELECTRICAL DS801-111
Input
Video+ Stereo Audio
Video/Sync/Audio Signals
ALTINEX Standard
Output
Video Analog Signal 1.0 Vp-p max.
Video Sync Level TTL
Audio Level 0 dB +/- 0.5 dB at 1 KHz
Power Consumption
External Adapter: 9 VDC 410 mA (3.7 W) max.
Table 3. DS801-111 Electrical
