PARTS AND FEATURES
1 2 3 4 5 6 7
8 9
Control Panel
Front View (Open)
1
Cup Shelf
2 Detergent Dispenser
3 Cutlery / Silverware
Basket
4 Filter Assembly
5 Rinse-Aid Dispenser
6 Water Spray Arm
7 Rack
Rear View
8
Drain Pipe Connector
9 Water Inlet Pipe
Connector
1 Rinse-Aid Warning Indicator 4 Wash Program / Cycle Selector Knob
2 Start / Reset Light 5 ON / OFF Power Button
3 Start / Reset Button 6 Power Indicator Light
