Condensing Units
CUS 15 - 60
Chillers & Condensing Units
Technical Manual : v1.2.0 07_2014
7
Technical Data
CUS
15D
20D
25D
30D
40D
50D
60D
Nominal Capacity
(1)
kW
41.8
50.2
71.1
80.7
104.0
131.4
161.4
Nominal Input
(1)
kW
13.8
17.4
23.5
28.8
43.2
54.6
61.8
Capacity Steps
%
0-50-100 0-50-100 0-50-100
0-50-100
0-25-50-
75-100
0-30-60-
80-100
0-25-50-
75-100
Construction
Material
Galvanised Steel
Colour
Charcoal Grey (RAL 7022)
Condenser
Type
Air Cooled
Quantity
2
2
2
2
2
2
2
Face Area
m²
2.47
3.46
3.46
3.46
5.75
5.75
5.75
Nominal Airflow
m³/s
4.00
4.80
6.80
6.80
9.60
13.60
13.00
Discharge
Vertical
Fan
Type
Axial
Quantity
2
2
3
3
4
6
6
Diameter
mm
610
610
610
610
610
610
610
Maximum Speed
rpm
930
930
930
930
930
930
930
Compressor
Type
Scroll
Tandem Scroll
Quantity
2
2
2
2
4
4
4
Oil Charge Volume
L
3.2
3.8
4.0
6.6
3.8
3.8/6.6
6.6
Refrigeration
Number of Circuits
2
Refrigerant Type
R407C
Holding Charge
Inert Gas
Dimensions/Weights
Height
mm
1438
1438
1438
1438
1693
1693
1693
Width
mm
2300
2900
2900
3000
2440
2440
2440
Depth
mm
1100
1100
1100
1100
1800
1800
1800
Machine Weight (nom)
kg
440
540
550
695
978
1119
1356
Operating Weight (nom)
kg
450
550
560
705
993
1139
1381
Connections
Suction
}
Sweat
in
1 1/8
1 1/8
1 1/8
1 3/8
1 5/8
2 1/8
2 1/8
Liquid
in
5/8
5/8
5/8
5/8
1 1/8
1 1/8
1 1/8
(1)
Nominal Capacity based on 5°C evaporating and a 35°C ambient.
