Time Electronics 1071 Capacitance Decade Box User Manual
Page 2

2
V1.1
P a g e
| 2
1071 Technical Manual
C ontents
All Time Electronics' instruments are subject to continuous development and improvement and in
consequence may incorporate minor detail changes from the information contained herein.
1.
S pecification
RANGE
TYPE
ACCURACY
@ 1kHz
MAX
VOLTAGE
TEMP
COEFF
ppm/degC
max
POWER
FACTOR
@ 1kHz
INSULATION
TO CASE
RESISTANCE
9 x 10pF
Silver mica
1% ± 5pF
300V dc
200V ac
200
< 0.0025
> 50G ohms
9 x 100pF
Silver mica
1% ± 5pF
300V dc
200V ac
200
< 0.0015
> 50G ohms
9 x 1nF
Silver mica
1% ± 5pF
300V dc
200V ac
50
< 0.002
> 50G ohms
9 x 10nF
Silver mica
1%
100V dc
72V ac
50
< 0.01
> 30G ohms
9 x 100nF
Poly-
carbonate
1%
100V dc
72V ac
75
< 0.01
> 30G ohms
9 x 1µF
Poly-
carbonate
1%
100V dc
115V ac
75
< 0.01
> 30G ohms
9 x 10µF
Polyester
5%
63V dc
50V ac
300
< 0.01
> 30G ohms
Zero Residual Capacitance:
≈
55pF
Operating Temperature:
0 to 70°C
Construction:
The case is of robust metal construction finished in
two-tone blue and black. A removable protective boot
houses the instrument
Dimensions:
215 x 100 x 120mm (incl. protective boot)
200 x 75 x 110mm (without)
Weight:
1kg (incl. protective boot), 0.6kg (without)
