Time Electronics 1065 Power Resistance Decade Box User Manual
Page 2
2
V1.1
P a g e
| 2
1065 Technical Manual
C ontents
All Time Electronics' instruments are subject to continuous development and improvement and in
consequence may incorporate minor detail changes from the information contained herein.
1.
S pecification
If voltages above 70V DC or 30V AC (RMS) are present the optional terminal shroud
kit (Part No. 9723) must be fitted.
Resistance Range:
0.1Ω to 120kΩ
Accuracy:
0.1Ω decade = ±5%
1Ω - 120kΩ decades = ± 1%
Number of Decades:
6
Increment:
0.
1Ω steps
Power Rating:
10 watt per resistor
Voltage Rating:
Maximum 500V DC/AC RMS
Temperature Coefficient:
200ppm/ºC
Residual Resistance:
Less than 2
0mΩ
Connections:
4 mm terminals. A third terminal is to enable the
case to be earthed or connected to either output.
Dimensions:
W390 x H60 x D150mm
Weight:
2kg
Features:
Ventilated robust metal case and multi-wafer
switches for low switch contact resistance
Optional Extras:
Calibration certificates traceable to NPL and
UKAS (ISO 17025).
