Time Electronics 1049 PT100 Simulator - Manual (Page 4)

3
1049 Technical Manual 3
2. Specifications
Technical Specification
Set Points °C:
-200, -100, -50, -20, -10, 0, 10, 20, 30, 40, 50, 60, 80, 100, 150,
200, 250, 300, 400, 500, 600, 700, 800.
Accuracy:
- 200 to - 100°C
- 50 to + 60°C
+ 80 to + 200°C
+ 250 to + 500°C
+ 600 to + 800°C
+/- 0.3°C
+/- 0.15°C
+/- 0.3°C
+/- 0.5°C
+/- 0.65°C
Temp Coefficient: Less than 30 ppm per °C
Maximum Current: 50 mA
General Specification
Dimensions: 61 x 112 x 55 mm (2.4 x 5 x 2.2 “)
Weight: 170 gm (6oz)
Optional Extras: Calibration Certificates – traceable to NPL and UKAS
Order codes and Optional Extras
Code Description
1049 Handheld PT100 °C Simulator (supplied with leatherette carry case)
9161 Factory (NPL Traceable) Calibration Certificate
9114 UKAS Calibration Certificate (ISO 17025)
