Controls, C ontrols – Time Electronics 1041 Resistance Decade Box User Manual
Page 5
4
1041 Technical Manual
4
3.
C ontrols
1) 5 way Decade Bank
Selects Output value of resistance.
2) Black 4mm terminals
Resistance output terminal.
3) Red 4mm terminals
Resistance output terminal.
4) Grey 4mmTerminal
A third terminal is to enable the case to
be earthed or connected to either output.
1 2 3 4
