Seametrics WMX-Series - Manual (Page 4)

GENERAL INFORMATION
IP68 Housing Option
(For 4”-10” meter;
standard for 3” models)
Power/Output cable port access, tamper-sealed
(NOTE: WMX101 comes with standard 20’ cable installed)
Powder-coated ductile cast iron electronics housing
Rate and total indicator
Internal Data Logger (Optional)
Equalization lug
Tamper-evident security seal &
cross-drilled screws (2) for tamper-evidence
Flanges, ANSI 150 lb. drilling
Equalization lug
Rate and total indicator
Internal Data Logger (Optional)
WMX104-300
(IP68 housing standard for 3” models)
Glass filled molded plastic liner
Power/Output cable port access, tamper-sealed
(NOTE: WMX101 comes with standard 20’ cable installed)
316SS electrodes
Powder-coated ductile cast iron body & electronics housing
Tamper-evident security seal &
cross-drilled screws (2) for tamper-evidence
Page 2
FEATURES Continued
