Rola-Chem Digital Controller PN 554135 02/17/2014 Page: 6 of 20

NOTE: When automating any body of water, it is essential to size the feeders to reach
desired levels in a relatively short period of time. Generally, automating an existing body of
water with existing feeders will require the output of the feeders be increased accordingly. If
feeders are unable to keep up with demand in a short period of time, automation becomes
ineffective.


3.2 Specifications

ORP & pH Ranges ORP

pH .

Display:

0 to 995 mv.

6.8 to 8.4

Control:

400 mv to 900 mv 7.0 to 8.0

(5 mv increments)

Factory default:

650 mv

7.4

Input Power
120 Volts AC, 50/60 HZ, 3 wire grounded power cord.

Combined load not to exceed 10 amps.

GFCI source required

Output Power

120 Volts AC, 50/60 HZ, 5 amps (fused) for both ORP and pH

Two 3-wire grounded power receptacles

Terminal strip for hardwire applications (included)


Displays:

ORP and pH – red digital
Power and flow indicator - LED
Alert indicator & Feed indicator- LED (ORP & pH)
Mode indicator- LED (pH ,ORP , Auto)


NOTE- feed lamps flash during the feed time and are on constant during the delay time of
the feed cycle.

O

perating Temperature: 40 to 120° F


Selectable Features
+ ORP and pH settings + High and low ORP and pH alerts + ORP and pH feed/delay
times
+ Manual feed

+ pH calibration

+ Acid/base feed

+ Keypad Lockout

+ Adjustable time-out + ORP and pH Interlock

+ Reset

Features and Options
+ Flow switch input

+ Individually fused outputs + 120 vac transformer
