Dimensions and Specifications
Section 6
Specification – Model 4085
Description Model 4085
Lamp Type 750Q/CL
Total Power Dissipated at 120 Volts, Watts 750
Current, Amperes 6.3
Approximate Focal Point Diameter, Inches (mm) 0.25 (6)
Heat Flux Density at Target Surface Without Shield, Watts/Sq in. (W/sq.
cm) 200 (31)
Heat Flux Density at Target Surface With Shield, Watts/Sq. in. (W/sq. cm) 650 (101)
Duty Cycle Without Air Cooling, “On” Time, Percent of Duty Cycle 35 %
Duty Cycle Without Air Cooling, Maximum “On” Time Minutes 6 min.
Duty Cycle With Air Cooling, “On” Time, Percent of Duty Cycle 100%
Cooling Air Required 120 SCFH
4085 Weight 4.5 lbs.
Emitter Life 500 hours @ 120V
Ordering information – Model 4085
Model Product Description
4085-00-750-00-00 4085, 750W Lamp, No controller
4085-00-750-01-00 4085, 750W Lamp, Model 5420-120 controller (includes potentiometer)
4085, 750W Lamp, Model 5420E-120 controller (includes pot, and time
4085-00-750-02-00
4085, 750W Lamp Model 5420MA-120 controller (includes 4-20 mA input
control) 4085-00-750-03-00
Accessories, Spare and Replacement Parts
Model Description
032914-000
Reflector Shield, Full-cut (interchangeable with internal reflector)
034900-000 Reflector Shield, Circle-cut
034901-000 Reflector Shield, C-cut
057550-006 Halogen Lamp, 750 Watt
057550-005 Halogen Lamp, 500 Watt
