Model 2200C Page 25
0-500 uS 0.5 2000
0-1000 uS 0.5 1000
0-2000 uS 1.0 1000
0-5000 uS 1.0 400
Range mS Required Cell Constant R68 Value
0-10 mS 10 2000
0-20 mS 10 1000
0-50 mS 10 400
0-500 mS 50 200
0-1000 mS 50 100
c) Set the temperature simulation DIP switch No. 1, S43 ON and Switch No. 2
OFF. This is to simulate 25°C. Set the conductivity simulation DIP switch No. 1,
S44 ON and switch No. 2 OFF. The display should indicate mid-range ±5%.
(For example, for range 5000 µS, cell constant is 1 and R68 = 400 Ohms
display should be 2500 µS ±5%.)
d) Now set the conductivity simulation DIP switch No. 1, S44 OFF and switch No.
2 ON. The display should show full range ±5%.
NOTE: Do not use this mode for calibration if both c) and d) are satisfied the
analyzer is in order and the problem is with the probe.
9.2 Escape
9.2.1 If the instrument appears to be "DEAD", for example not responding to the buttons,
or not performing on line measurement and control, always try the reset feature
first, as described in 6.3.1.
9.2.2 a) The "ESCAPE" procedure is to be used normally at the factory only, when the
unit is powered with a new processor. As a result, the internal non-volatile
memory (EPROM) is "FORMATTED" and the factory values are loaded into it.
b) The "ESCAPE" procedure is to be used if a unit is serviced for a new processor,
or in case of a memory loss problem, when so advised by AquaMetrix service
support.
9.2.3 Before performing the "ESCAPE" procedure it is important to know that this
procedure provides the option to erase all programmed values and replace them
