Using the ATAVRAUTO200

ATAVRAUTO200 User Guide

2-11

7698A–AUTO–01/07

2.6

Debugging

2.6.1

Debugging with AVR JTAGICEmkII

The ATAVRAUTO200 can be used for debugging with JTAG ICE MK II.

Connect the JTAG ICE mkII as shown in Figure 2-12 for debugging, please refer to AVR
Studio Help information.

This manual is related to the following products:

ATAVRAUTO200
