KROHNE OPTIWAVE 7300C FOUNDATION FIELDBUS - Manual (Page 2)

CONTENTS
2 www.krohne.com 02/2010 - 4000621601 - AD FF OPTIWAVE 7300 R01 en
OPTIWAVE 7300 C
1 General safety information 3
1.1 Scope of the document..................................................................................................... 3
1.2 Device description ............................................................................................................ 3
1.3 Scope of delivery............................................................................................................... 3
2 FOUNDATION Fieldbus data 4
3 Electrical connections 5
3.1 Electrical installation: terminals ..................................................................................... 5
3.2 Electrical connection: PACTware™.................................................................................. 6
4 Operation 7
4.1 Description of device data ................................................................................................ 7
4.1.1 Resource block ....................................................................................................................... 7
4.1.2 Transducer block .................................................................................................................... 7
4.1.3 Measurement data.................................................................................................................. 8
4.1.4 Status data .............................................................................................................................. 8
5 Notes 9
