Acoustic Energy AegisNeo Series - Manual (Page 8)

Power amplifier 150 watts rms into 8 ohms
Drive unit One front facing 220 mm pulp cone
bass unit
S/N ratio >75 dB
Power handling 150 watts programme rating
Crossover frequency range 35 Hz – 100 Hz active/passive
Connections Line level gold-plated RCA phono jacks
5-way binding posts
Cabinet Precision engineered, low resonance
25 mm/36 mm MDF throughout, with
front-facing drive unit in a sealed
enclosure
Cabinet finish Black Ash vinyl
Grille Precision engineered, protective grille
(non-removeable)
Weight (excl. packaging) 15 kg
Dimensions (WxHxD) 380x360x310 mm
SUMMARY OF FEATURES
• Auto on/off • Gold-plated RCA phono jacks • 5-way binding posts
• Line input and high level input capability • High pass line level output
• High level speaker output • Phase control switch • Variable crossover
frequency • Volume level control • Thermal output protection circuit included.
Specifications
