START-UP
4
9
IFC 070
www.krohne.com 11/2010 - 7311222400 - QS IFC 070 R04 en
4.1 Connection of battery
4.1.1 Internal battery
• Remove the blue protection cap.
• Loosen the 4 Allen bolts (4 mm).
• Remove the cover.
• Fasten the battery connector to the internal connector in the converter.
• Check that the display lights up.
• Put the cover back.
• Tighten the 4 Allen bolts.
• Put the blue protection cap back.
CAUTION!
Please connect battery before first use, see relevant chapter for your type of battery.
Each converter is always delivered with a disconnected battery.
Figure 4-1: Connecting battery
WARNING!
Make sure that the battery cable is not jammed by the cover.
INFORMATION!
The instrument now operates with factory set parameters.
For configuration of these settings, please refer to the handbook and/or the documentation of
the converter.
