Speaker Mounting Details
The following illustrations define the requirements for mounting the
speaker on the near and far sides of the mounting surface or inde-
pendent mounting board.
TYPICAL SPEAKER INSTALLATION
FACTORY SPEAKER REPLACEMENT
MESH GRILLE
APPLY BUTYL PUTTY
(4 PLACES)
MACHINE SCREW
SPEAKER
MOUNTING SURFACE
GRILLE
NUT
MOUNTING
SURFACE
MESH GRILLE
APPLY BUTYL PUTTY
(4 PLACES)
SHEET METAL
SCREW
SPEAKER
GRILLE
SPEED
CLIP
FACTORY
GRILLE
SPEAKER
EXISTING FACTORY
HARDWARE
MOUNTING
SURFACE
