Specifications
Notes
1 The XFP/SFP interfaces of the UTA module meet the requirements stated in the MSA standard
2 Requires XFP/SFP that must be ordered separately (see the ordering guide)
Interfaces and Signal Specifications
Signal Port/Connector Format
STM-64 / OC-192 One XFP port 1 - SDH: as per ITU-T G.707
- SONET: as per Telcordia GR-253-Core
STM-1 / STM-4 / STM-16 (option)
OC-3 / OC-12 / OC-48 (option)
One SFP port 1 - SDH: as per ITU-T G.707
- SONET: as per Telcordia GR-253-Core
Bantam 100 Ohms E1 (2.048 Mb/s) / DS1 (1.544Mb/s)
Clock Input
BNC 75 Ohms 2.048MHz/1.544MHz/10MHz
BNC 75 Ohms 2.048MHz/1.544MHz
Clock Output
SMA 50 Ohms 622.08 MHz (with STM-4/16/64)
155.52 MHz (with STM-1)
Data Communication Channel DB-15 connector D1-D3: 192 Kb/s channel
D4-D12: 576 Kb/s channel
Optical Interfaces 1,2
Ref. Interfaces Wavelength Output Power Reach Overload Sensitivity
5610-141-UTA SR-1 / I-64-1 1290 – 1330 nm -6 to -1 dBm 10 km -1 dBm -11 dBm
5610-150-UTA SR-1 / I-64.1 1290 – 1330 nm -6 to -1dBm 10km -1dBm -11dBm
5610-142-UTA IR-2 / S-64.2b 1530 – 1565 nm -1 to +2 dBm 40km -1dBm -14dBm
XFP
5610-143-UTA
LR-2/L-64.2 1530 – 1565 nm 0 to +4 dBm 80 km -7 dBm -24 dBm
5610-144-UTA LR-1 / L-16.1 1280 – 1335 nm -2 to +3 dBm 40 km -9 dBm -27 dBm
SFP
5610-145-UTA LR-2 / L-16.2 1500 – 1580 nm -2 to +3 dBm 80 km -9 dBm -28 dBm
Clock Synchronization
Clock Reference • Internal stratum 3 clock generation
• External 2.048 MHz reference clock
• Timed from 2.048 Mbit/s received signal
• External 1.544 MHz reference clock
• Timed from 1.544 Mbit/s received signal
• External 10 MHz reference clock
• Timed from SDH/SONET received signal
