MODELS 341A-342A-344A
7
NOTES:
1. BRONZE FITTED CONSTRUCTION WILL BE FURNISHED AS STANDARD UNLESS
SPECIFIED.
2. REFER TO FACTORY FOR SPECIAL ALLOYS.
3. AURORA PUMP RESERVES THE RIGHT TO SUBSTITUTE MATERIALS WITHOUT
NOTICE
4. PIECE NUMBERS 14 AND 15 ARE NOT FURNISHED AS STANDARD, WHEN FUR-
NISHED, IMPELLER MUST BE MODIFIED.
5. PIECE NUMBERS 39, 40, 41 USED ONLY WITH MOTOR FRAMES 143 THRU 184-JM
ON MODEL 341A PUMPS.
NOTE
WHEN ORDERING SPARE PARTS ALWAYS INCLUDE THE PUMP
TYPE, SIZE, SERIAL NUMBER, AND THE PIECE NUMBER FROM THE
EXPLODED VIEW IN THIS MANUAL.
ORDER ALL PARTS FROM YOUR LOCAL AUTHORIZED DISTRIBUTOR, FACTORY
BRANCH SALES OFFICE OR THE FACTORY AT NORTH AURORA, ILLINOIS.
1. Elbow
2. Connector
3. Tubing
4. Plug, Pipe
5. Capscrew
6. Casing
7. Wear Ring
8. Gasket
9. Impeller Screw
MODEL 341A LIST OF PARTS
9A. Washer
9B. Gasket
9C. Capscrew Seal
10.
Gasket
11. Impeller
12. Impeller Key
14. Wear Ring
15. Wear Ring
16. Wear Ring
25. Sleeve
27. Seal
32. Capscrew
33. Screw
34. Nameplate
35. Bracket
39. Capscrew
40. Washer
41. Support
61. Pin
1. Elbow
2. Connector
3. Tubing
4. Plug, Pipe
5. Capscrew
6. Casing
7. Wear Ring
8. Gasket
9. Impeller Screw
9A. Washer
MODEL 342A LIST OF PARTS
9B. Gasket
9C. Capscrew Seal
10.
Gasket
11. Impeller
12. Impeller Key
14. Wear Ring
15. Wear Ring
16. Wear Ring
25. Sleeve
27. Seal
32. Capscrew
33. Screw
34. Nameplate
35. Bracket
39. Capscrew
61. Pin
72. Gasket
73. Base
74. Plug, Pipe
75. Plug, Pipe
1. Elbow
2. Connector
3. Tubing
4. Plug, Pipe
5. Capscrew
6. Casing
7. Wear Ring
8. Gasket
9. Impeller Screw
9A. Washer
9B. Gasket
9C. Capscrew Seal
10.
Gasket
11. Impeller
12. Impeller Key
14. Wear Ring
15. Wear Ring
16. Wear Ring
MODEL 344A LIST OF PARTS
25. Sleeve
27. Seal
32. Capscrew
33. Screw
34. Nameplate
35. Bracket
39. Capscrew
40. Washer
41. Support
42. Key
43. Grease Fitting
44. Tube, Vent
46. Plug, Pipe
47. Slinger
47A. Slinger
48.
Capscrew
49. Bearing Cap
50. O-Ring
51. Seal
51A. Seal
52.
Retaining Ring
53. Bearing
54. Bearing
55. Shaft
56. Plug, Pipe
57. Frame
58. Grease Fitting
59. Plug, Pipe
60. Oiler Assembly
61. Pin
62. Capscrew
63. Washer
64. Support
