SPECIFICATIONS
Network Camera
MPEG4/MJPEG Dual Codec
SecureNet NetServer 6001
*
Video
Video compression
Video frame rate
Compression rate selection
Frame rate setting
Video resolution
Image rotation
Digital zoom
Motion detection
Audio
Line in
Communication
LAN port
Communication protocol
Video Streaming
System
CPU
RAM
Flash ROM
OS
I/O
Alarm Input
Alarm output
Analog video input
Analog video output
Analog audio input
PTZ camera control
Ethernet
Software
Browser
Application Software
OS supported
Software Features
1. System
2. TCP/IP
3. Users
4. Date/ Time Setting
MPEG4 / JPEG (dual codec),H.263(for 3GPP)
Up to 30fps for all video resolutions
5 levels: best, better, normal, faster, fastest
PAL: 1, 2,3,4,5,6,12,25 ; NTSC: 1,2,3,4,5,6,7,10,15,30 fps
NTSC: 176x112, 320x240, 640x480, 704x480
PAL: 176x144, 352x240, 640x480, 704x576
Mirror / Up side down
Yes, x 1/2, x1, x 2, x 4 times
Yes (3 windows)
Yes
PCM 8k sampling, 16-bit stereo
RJ-45, 10/100M auto-sensed, auto crossover
HTTP, RTSP, FTP, SMTP, TCP/IP, UDP, ARP, ICMP, DHCP, PPPoE, DDNS,
UPnP, SAMBA,3GPP
Multicasting / RTSP / Over HTTP
32bit RISC CPU
32MB
4MB
uCLinux
2
1
1 x BNC
1 x BNC (pass through)
1 x 3.5mm Jack
1x RS-485
1x RJ45
Internet Explorer 6.0 or above
CentaView application software
Microsoft Windows 2000, XP
Name
LED Control : ON/OFF/FLASH
Static IP Address
- IP Address
- Subnet Mask
- Default Gateway
Dynamic IP Address
- DHCP
- PPPoE
--User ID
--User Password
Primary DNS Address
Secondary DNS Address
Dynamic DNS
UPnP
IP filter
Three levels
Administrator / Operator / Viewer
Date: Year/Month/Day
Time: Hour/Minute/Second
NTP Protocol
NTP Server Address
Time Zone
5 levels: best, better, normal, faster, fastest
NTSC: 1,2,3,4,5,6,7,10,15,30 fps; PAL: 1, 2,3,4,5,6,12,25
NTSC: 176x112, 320x240, 640x480, 704x480
PAL: 176x144, 352x240, 640x480, 704x576
Yes
Yes
FTP
SMTP
SAMBA
Service
User Name
Password
Domain Name
Motion Sensitivity
Motion mask is easily set
Video loss
Reboot
Motion detection
Alarm-in
Schedule
Send video e-mail
Upload video file to ftp server
Save video file to network share
Send notification to specified TCP/HTTP server
Control camera to preset location
Turn on alarm output
Pan / Tilt driver can be uploaded and changed dynamically
Supports pelco and A-Linking protocols
CGI commands to control camera
Media SDK to handle streaming
Reset to factory default setting
DC 12V,1.5A, switching type power supply
10W (800mA x 12V), maximum
Green color
Green color
176mm(L) x 114mm(W) x 32mm(H)
5°C ~ 40°C
-20°C ~ 50°C
10% ~ 80% non-condensing
FCC / CE class B
5. Video
Compressing Rate
Frame Rate:
Video Resolution
Brightness Control
Contrast Control
6. Upload configuration
7. Dynamic DNS
8. Motion Detection
9. Events
10. Triggered Actions
11. P / T Control
12. Open API
13. Other
Power
Power
Power consumption
LED
Link LED
Alert LED
Size
Main body
Operating environment
Operating temperature
Storage temperature
Humidity
EMI
ORDERING INFORMATION
Model Name Description
NetServer 6001 Standard Video Serverr with Ethernet Interace
NetServer 6001P Video Server with Power Over Ethernet Interface
NetServer 6001W Video Server with Ethernet and Wireless Interface
