STEP 15
Attach handle/towel bar to side panel with 1 1/4” #8 screws and washers from inside side panels.
1 1/4” Phillips Flat Head #8 Screw (23)
2 Used in this step
ILLUSTRATION 15
STEP 14
A. Attach the Back Splash to the back edge of the Table
Top with 1 1/4” #8 Screws in three places as shown.
Next, start one 1 1/4” #8 Screw through each upper
hole in Back Splash into pilot holes on short flat edge
of the BS-6 Side Splashes.Then take the 1 1/4”
Screws, come up through the bottom of the Table
Top, align the Screw with the pilot hole in the
BS-6, and when all screws are aligned in their
respective pilot holes, tighten down.
ILLUSTRATION 14
1 1/4” Phillips Flat Head #8 Screw (23)
7 Used in this step
4 used in
this step
Handle can go on either side. Knife
rack will go on the other side.
