APH 8104
10.4” high brightness LCD
Industrial panel mount monitor
2-2 Structure Diagram
Front View
Rear View
1. Rear Case
2. Class A TFT LCD Panel
3. 4mm Protective Glass
4. 6mm Aluminum front Bezel
5. LCD Membrane
