Parts List
When unpacking the completely assembled vise check to make sure there are no missing
or broken parts. Call Yost Vises at (616) 396-2063 or email us at
[email protected]
should a problem arise.
Parts List 3D “General Purpose Drill Press Vise”
Part
Description Quantity
3D-01 Front Jaw 1
3D-02 Serrated Jaw 2
3D-03 Allen Screws 4
3D 04 Pipe Jaws 0
3D-05 Pipe locking Pin (front jaw) 0
3D-06 Pipe locking Pin (back jaw) 0
3D-07 Main Screw & Handle 1
3D-08 Flat Washer 1
3D-09 Locking Collar 1
3D-10 Vise Nut 1
3D-11 Vise Nut locking pin 1
3D-12 Back Jaw 1
3D-13 Lock Down 2
3D-14 Swivel Base (Outer) 1
3D-15 V-grooved inner base 1
3D-16 Lock Down bolts 2
Full Version Of Terms And Conditions Of Sale
Available on-line at
www.yostvises.com (select terms of sale).
Yost Vises
388 West 24
th
Street
Holland, MI 49423
(616) 396-2063
(616) 396-8276 Fax
www.yostvises.com
[email protected]
