Parts List
Item # Stock # Descriptions Qty Item # Stock # Descriptions Qty
1 3710-001 Screw 20 44 3710-044 Arbor bolt 1
2 3710-002 Motor cover 1 45 3710-045 Riving knife 1
3 3710-003 Brush holder 2 46 3710-046 Support board 1
4 3710-004 Carbon brush 2 47 3710-047 Connector board 1
5 3710-005 Motor housing 1 48 3710-048 Flat washer 1
6 3710-006 Screw 3 49 3710-049 Lock nut 40
7 3710-007 spring washer 5 50 3710-050 Shaft 1
8 3710-008 Flat washer 5 51 3710-051 Adjustment board 1
9 3710-009 stator 1 52 3710-052 Spring washer 1
10 3710-010 Flat washer 6 53 3710-053 Bolt 12
11 3710-011 Screw 2 54 3710-054 Lock washer 8
12 3710-012 Bearing 1 55 3710-055 Nut 2
13 3710-013 Rotor 1 56 3710-056 Nut 3
14 3710-014 Bearing 1 57 3710-057 Fixing board 1
15 3710-015 Wind washer 1 58 3710-058 Square plate 1
16 3710-016 Gear box 1 59 3710-059 Lock shaft 1
17 3710-017 Bearing 1 60 3710-060 Pin 1
18 3710-018 C-ring 1 61 3710-061 Release lever 1
19 3710-019 Wave washer 1 62 3710-062 Anti-kickback device 1
20 3710-020 Gear 1 72 3710-072 Blade guard assembly 1
21 3710-021 Spindle 1 93 3710-093 Fixing shaft 1
22 3710-022 C-ring 1 94 3710-094 Angle pin 1
23 3710-023 Bearing 1 95 3710-095 Nut 1
24 3710-024 Gear box cover 1 96 3710-096 Nut 4
25 3710-025 spring washer 3 97 3710-097 Support board B 1
26 3710-026 Screw 3 98 3710-098 Flat washer 2
27 3710-027 Key 1 99 3710-099 Pin support 1
28 3710-028 Screw 3 100 3710-100 Screw 1
29 3710-029 spring washer 4 101 3710-101 Bevel locking knob 1
30 3710-030 Washer 3 102 3710-102 Bolt 2
31 3710-031 Terminal block 2 103 3710-103 Finger board 1
32 3710-032
Terminal
4 104 3710-104
Washer
1
33 3710-033 Copper sheet 2 105 3710-105 Big washer 4
34 3710-034 6.3 Terminal 4 106 3710-106 Support board A 1
35 3710-035 6.3 Insulating soft sheath 4 107 3710-107 Wave washer 2
36 3710-036 Connector 1 108 3710-108 Screw 1
37 3710-037 Strain relief 1 109 3710-109 Tube 3
38 3710-038 Motor wire cord 1 110 3710-110 Bolt 4
39 3710-039 C-ring 1 111 3710-111 Adjustment board 1
40 3710-040 Bushing 1 112 3710-112 Pin 1
41 3710-041 Inner flange 1
42 3710-042 Blade 1
43 3710-043
Outer flange
1
