EB-5531
High Performance GPS Engine Board
2010/8/2 - 5 -
Receiver Performance
Sensitivity
Tracking :
Autonomous acquisition :
-163dBm
-160 dBm
Time-To-First-Fix
Cold Start
– Autonomous
Warm Start – Autonomous
Hot Start
– Autonomous
< AVG 35s
< 35s
< 1s
Horizontal Position Accuracy Autonomous
< 2.5m
Velocity Accuracy
Speed
Heading
< 0.01 m/s
< 0.01 degrees
Reacquisition 0.1 second, average
Max Update Rate 1 Hz
Maximum Altitude < 18,000 meter
Maximum Velocity < 515 meter/ second
Maximum Acceleration < 4G
1.50% -130dBm Fu 0.5ppm Tu
±2s Pu 30Km
2.Commanded Warm START
3.Commanded Hot START
4. 50% 24hr static, -130dBm
5. 50% @ 30m/s
Environmental Characteristics
Parameter Min Typ Max Unit
Humidity Range 5 95 % non-condensing
Operation Temperature -40 25 85
℃
Storage Temperature -40 85
℃
Physical Characteristic
Type 20-pin stamp holes
Dimensions 15 mm * 13 mm * 2.4 mm ±0.2mm
