13

TM104N

Revised

1.27.14

Illustration 9

Passenger side.

Front of vehicle

Coupler assembly

PN 90-4053

PN 90-2014

Illustration 10

Passenger side shown.

See note 16. This

hole must be drilled.

Use 7/16” X 1 1/4”

bolts.

PN 82-1455 Driver

PN 82-1466 Passenger

PN 90-1496

Front of vehicle

9/16” X 1 1/2”

2 places.

3/8” X 2 1/4”

2 places.
