ANUBIS Typhoon Wireless Access Point User Manual
Page 15
Typhoon Speednet Wireless Access Point
14
l
Setting up IP/SNMP settings
-
When operating in Wi-Fi mode, the AP runs an IP stack. The IP
settings can be modified by selecting the "IP/SNMP" settings in the
Profiles menu of the AP manager. The following parameters can be
modified:
u
DHCP Enabled
- When enabled, the AP will attempt to obtain an IP address through
DHCP.
u
IP Address
- Allows for manually assigning an IP address.
u
Default Gateway
- Allows for manually assigning a Gateway (enter Gateway’s IP address).
u
Subnet Mask
- Allows for manually entering a subnet mask.
- The AP provides an SNMPv1 agent and provides support for the
standard IEEE 802.11 MIB and proprietary extensions. These objects
can be read and configured via a standard SNMP MIB Browser. The
following parameters can be set on the AP by selecting the "IP/SNMP
Settings" from the Profiles menu in the AP Manager:
u
Community Name – GET
- The read password to monitor AP/Access Point statistics and
configuration parameters. Default password is "public".
u
Community Name – SET
- The read / write password to monitor AP statistics and edit
configuration parameters. Default password is "private".
u
Community Name – TRAP
- The password included in trap messages sent to the SNMP
management tool. This password can be used to filter unwanted
messages. Default password is "public".
u
Trap Target
- The IP address of the SNMP management station that will collect
SNMP trap messages. Default address is "192.168.0.1".
