3. Connector
3-1. Explanation of a connector terminal
CN
Terminal Name
Function
CN2
1
XL
Touch screen Input XL.
2
YU
Touch screen Input YU.
3
XR
Touch screen Input XR.
4
YD
Touch screen Input YD.
CN4
1
Vbus
USB Vbus
2
D-
USB D-
3
D+
USB D+
4
GND
USB GND
5
Shield
USB FG
3-2. The mounted connector
CN
P/N
Manufacturer
CN2
00-8370-049-000-800+
Kyosera Elco Corporation
CN4
S5B-PH-K-S
J.S.T. Mfg Co., Ltd
