PRODUCT DIAGRAM
(Actual product design may differ slightly from images below)
5
FRONT
A. Control panel
B. Vertical air louvers
C. Air outlet
D. Horizontal air louvers
E. Casters
F. Power Cord & Plug
BACK
A. Hot air outlet grill
B. Lower air inlet grill
ACCESSORIES
Flexible exhaust hose with 2 adapters
• 3-piece set
• stretches from 14 1/4” to 60 5/8”
(36cm to 150cm)
Adjustable window slider kit
• 2-piece set
• adjusts from 28.5” to 55"
(72.4cm to 139.7cm)
Drain tube & Pan
