© American Audio ® - www.AmericanAudio.us - PXI 12P™ - Instruction Manual Page 15
Model: American Audio® PXI 12P™ - Professional
Powered Sound Reinforcement Loud Speaker
Speaker Section:
Dimensions: 12” (L) x 15.5” (W) x 22” (H) / 305mm x 393mm x 559mm
Weight: 53.5 Lbs. / 20 kgs
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (non-condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Frequency Response: 40KHz - 20KHz (-3dB)
Crossover: 3,500 HZ
Nominal Dispersion: 90˚ x 50˚ (HXV)
Amplifier Section:
Power supply: AC 115v/230v, 50/60Hz
Power consumption: 12 Watts Typical
Accessories: I.E.C. Power Cord
Input Sensitivity
Line:
80mV
Microphone: 5mV
Output Sensitivity: 96.5 ± 2dB/m/w
Channel Equalizer:
Bass:
+/-12dB
Treble: +/-12dB
NOTES:
The specifications are subject to change to any improvement by negotiations in advance.
The parts are subject to change to any improvement within the range of the specifications.
PXI 12P™ Technical Specifications
