SoleusAir PH4-13R-01 - Manual (Page 3)

3
SPECIFICATIONS
• The cooling capacity is measured at an ambient temperature of DB 86 °F, WB 78 °F.
• Noise level is measured at a distance of 3.28 ft away from the front of the unit, when the unit is in cooling mode.
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
• If the environment temperature is higher than the max operating temperature or lower than the minimum operating temperature,
the air conditioner may not work properly.
PACKAGE CONTENTS
Portable Air Conditioner
Exhaust Hoses (2)
Hose Adapters (2)
Window Kit Adapter (2)
Air Intake and Outlet Covers (2)
Remote Control
AAA Batteries (2)
Window Kit - 4 Sliding Panels (1 dual hose panel, 1 single hose panel, 2 extension panels)
Air Intake Vent for Single Hose Installation (Additional Accessory) (1)
Owner’s Manual
MODEL PH4-13R-01
COOLING CAPACITY 13,000 BTU/H
HEATING CAPACITY 12,500 BTU/H
DEHUMIDIFIER CAPACITY 60 pts/Day
POWER
COOLING 1390W
HEATING 1180W
AIR FLOW VOLUME 225 CFM
POWER SOURCE
115 V~ 60 HZ
11 A MP / 12.5 AMP
HEATING / COOLING
SOUND PRESSURE LEVEL 50 dB(A) at the lowest fan speed
NET WEIGHT 88 Lbs
OPERATING
TEMP
COOLING 60.8℉-107.6℉
HEATING 23℉-89.6℉
PRODUCT DIMENSIONS
REFRIGERANT R-410A
19” W ×18.5” D ×32.25” H
5()(5(1&(180%(5 LX-135DHP
