05-26763-0B Page 5
5. seCUre tHe leGs
To secure the legs to the roof assembly, insert each
of the 8 short pins (10051) through the hole at the
bottom of each of the 4-way connectors.
Rotate the legs, if necessary, to align the holes. This
will complete the leg assembly for this side. Repeat
for the other side.
Use Bungees to Secure Cover
Grommet
Panel
10066
Cover
6. PlaCe CoVer anD seCUre to CanoPY FraMe
A. Place cover over assembled roof frame with grommet panels facing down, aligned with cross poles.
B. Make sure the cover is properly aligned on the frame, secure the four corners of the cover with bungees
(10066) to the frame first . Attach remaining bungees. Re-adjust bungees position along cross pole as needed
to ensure a tight and even fit of the cover to the frame.
C. To secure the valance corners wrap the upper hook and loop tie just below the elbow. Do the same for the
lower hook and loop tie.
Note: This will keep the valance from rolling up but still allow for movement.
Secure Bungee Around Plastic Ball Insert Bungee Cord Through Grommet Hole
valance Cover Corners
Align Grommet Panels to Cross Poles
Grommet Panel
Cover
