Secure the legs, Anchor the frame – ShelterLogic 23572 10 x 20 Super Max Canopy 2-in-1 Pack - Enclosure Kit User Manual
Page 6
05-23572-0B
Page 6
5.
SECURE THE LEGS
To secure the center legs to the roof assembly, insert
each of the 4 short pins (10051) through the hole at
the bottom of each of the 4-way connectors.
Rotate the legs, if necessary, to align the holes. This
will complete the leg assembly for this side. Repeat
for the other side.
6. ANCHOR THE FRAME
A. There are four holes on each base foot that the anchor can go into. Select a hole in each base foot. Insert
each anchor into the ground until the round head is touching the base foot.
B. Insert one anchor into all eight base feet.
This is a temporary spike anchor. Not intended for permanent use.
ShelterLogic
®
Anchoring Kit #10073 is recommended.
Anchoring Base Feet
10431
10043
10050
