ShelterLogic 22587 12x12 Straight Leg Pop-Up User Manual
Page 4
05-22538-22539-22540-22541-
22542-22543-22587-0A
Page 4
Part
Part Number
Description
1
15466
Leg Tube Assembly
2
15471
Gemel Assembly
3
15474
Slide Tube Assembly
4
22603
TOP CREST KIT
5
22605
SLIDING CONNECTOR KIT
6
15479
Replacement Cover - Green
6
800796
Replacement Cover - Red
6
800797
Replacement Cover - Blue
6
800798
Replacement Cover - Black
6
800799
Replacement Cover - Desert Bronze
6
800800
Replacement Cover - Checkered Flag
6
802542
Replacement Cover - White
not shown
15575
Replacement Roller Bag
to order replacement Parts, Please order by Part number:
4
5
see
4
see
5
6
