ShelterLogic 22589 12x12 Slant Leg Pop-Up User Manual
Page 4
05-22544-22545-22546-22547
-22548-22549-22589-0A
Page 4
Part
Part Number
Description
1
15385
Leg Tube Assembly
2
15390
Gemel Assembly
3
15393
Slide Tube Assembly
4
22603
TOP CREST KIT
5
22604
SLIDING CONNECTOR KIT
6
15397
Replacement Cover - Green
6
800801
Replacement Cover - White
6
800802
Replacement Cover - Red
6
800803
Replacement Cover - Blue
6
800804
Replacement Cover - Black
6
800805
Replacement Cover - Desert Bronze
6
800806
Replacement Cover - Checkered Flag
not shown
15580
Replacement Roller Bag
to order replacement Parts, Please order by Part number:
4
5
see
4
see
5
6
