Fr ont re a r – ShelterLogic 70405 6 x 6 x 6 Shed-in-a-Box User Manual
Page 4
05-70401-70402-70405-0H
Page 4
800075
800071
800077
800076
800071
800176
800176
800176
800177
800177
800177
800076
800071
800077
800075
800071
1. lAYoUt rooF FrAMe
2. ASSeMBle rooF FrAMe
800075
800076
800077
TOP BEND CONNECTOR
SIDE BEND CONNECTORS
F
r
ont
re
A
r
NOTE:
Ensure that parts 800075 and 800076
are installed correctly. After assembly, the
welded socket for the cross rail will be below
the bend.
Side Bend Connectors
Welded Socket
for cross rail
Bend in pipe
