Specifications, 1 headphones, 2 microphone – SHARKOON X-Tatic SR User Manual

Page 4: 3 sound control unit (scu)

3. specifications

3.1

headphones

• Diameter: 40 mm with NdFeB magnet

• Impedance: 32 Ω

• Sound pressure level: 119 dB +/- 3 dB at 1 KHz

• Frequency response: 20 Hz – 20 kHz

• Power output: 30 mW

• Cable length: 400 cm +/-10 cm

• Connector: 1x 6-pin analog plug

3.2

microphone

• Dimensions: 6 x 5 mm

• Directivity: omni directional

• Sensitivity: -58 dB +/- 3 dB

3.3 sound control Unit (scU)

• 1x digital optical input (S/PDIF)

• 1x analog 3.5 mm audio input (line in / stereo)

• 1x 6-pin audio output for the X-Tatic SR headset (G6)

• 1x analog 3.5 mm audio output (line out / stereo) for additional headset

• 1x USB B connector (power and PS3

™

chat)

• Dimensions: 22.5 x 106 x 63 mm (H x L x W)

• Weight: ~89 g
