Tarea

Place the mainboard to the mounting panel. A stand-off must be screwed into every drilling
of the mounting panel visible through the mainboard’s screw openings.
3. Remove the mainboard and screw the stand-offs into the respective drillings of the
mounting panel (fig. 3).

(Stand-offs)

fig. 3

4. Press the I/O shield (delivered with the mainboard) into the I/O shield opening in the case’s
back side.

5. Place the mainboard back onto the stand-offs and screw the mainboard to them (fig. 4).

(Screws for mainboard mounting)

fig. 4
