SHARKOON Nightfall - Manual (Page 13)

NIGHTFALL
8. Installation of a 3.5" device
(1. Remove the case’s front panel by gently dragging it towards you.)
2. Dismantle the 5.25" front bezel from the mounting bay in which you intend to install the
drive by loosening its screws and pushing the bezel to the inside (fig. 15). Remove the quick
fasteners (fig. 16).
fig. 15 fig. 16
(Carefully take out an optionally present metal bezel covering the drive bay by using a
gripper.)
3. Screw the mounting angles to the 3.5" device from both sides (fig. 17).
fig. 17
4. Slide the 3.5" device with attached mounting rails into the case’s drive bay (fig. 18) and
screw it to the drive bay from both sides (fig. 19).
fig. 18 fig. 19
