X-TATIC SOUND CONTROL UNIT

X-TATIC SOUND CONTROL UNIT

21

A –

Optical audio input (S/PDIF)

B –

USB connector (for PS3 microphone)

C –

Buttons for volume (- / +) resp. Time-Delay (- / +)

D –

On / off button for Pro Logic resp.

Dynamic Range Control (DRC)

E –

SCU power on / off button

F

–

Switch between Time-Delay for surround and

center speaker

G –

Switch between volume / Pro Logic (VOL / PL)

and Time-Delay / Range Control (TD / DRC)

H –

ISO power connector

ENGLISH

A

B

C D E

F G

H
